100% new and high quality



Features:

Industrial grade LED digital tube display that can be easily read from any angle and light condition.

This product is suitable for products with 36V DC input and power less than 100W, such as fans, lights, and wave pumps.

Simulates sunrise and sunset to reduce stress on aquarium fish.

This timer has two modes, one with 15 minutes ramp up/down, the other is simply on/off.

Can be used as a dimmer, it can be adjusted from 1 to 100% brightness to meet the needs of different plants and pets in terms of light.

One button to turn on/off.

DO NOT connect any items if they exceed 30V or 120W.

Suitable for all Chihiros LED lights, A series, A plus series, RGB series, C series.



Installation:

Before installation, check the power supply and the lamp's power, which should be less than 100W. Check the lamp's interface (5.5mm DC head lock) and connect the modulator in series between the lamp and the power supply.

Step 1: Open the package and remove the dimmer.

Step 2: Connect the dimmer to the LED light.

Step 3: Connect the power to automatically turn on the dimmer.

Step 4: Set the dimmer parameter.

Key function



1. ON/OFF

Turn on/off the light.

Long press to set the current time, by pressing + and - you adjust hours and minutes.

Press \"Mode\" to exit time setting.

2. MIN/L+

Brightness increases.

3. HOUR/L-

Brightness decreases.

4. MODE

Hold for 3 seconds to enter programming mode.

The display flashes between no-1 and current time, press + and - to adjust.

Press the MODE key again to set the brightness.

Press the MODE key again, the display flashes between no-2 and current time.

Press the MODE key again to set the brightness.

Press the MODE key again to enter the next timed program, it can control and separate timed programs.

In this way, 8 sets of data are set. Press MODE to exit after setting.

Note: If the time is set to \"-- : --\", the data for that group will not work.



Specifications:

Material: Plastic

Model: S2-pro

Product connection: 5.5mm DC male with locking thread.

Product size: Length 7 cm/2.76 inches; Width 3.9 cm/1.53 inches

Quantity: 1 pc (other accessories shown in the picture are not included!)

Note: 1. Please allow 0-1 cm error due to manual measurement. Please make sure you do not mind before you bid.

2. Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!



Package includes (without retail packaging):

1 pc x Light Dimmer
