Application: welding machines
Model Number: E71T-1C
Weight: 0.5kg
Shielding gas: 100% CO2
Chemical composition of the deposited metal (%)
C Mn Si PS Cr Ni Mo V Cu
less than or equal to 0 12 less than or equal to 1 75 less than or equal to 0 90 less than or equal to 0 03 less than or equal to 0 03 less than or equal to 0 20 less than or equal to 0 50 less than or equal to 0 30 less than or equal to 0 08 less than or equal to 0 35
Mechanical properties of the registered metal
Performance element Tensile strength Point Elongation Resistance Impact toughness Charpy v-notch
(MPa) (MPa) (%) Temperature test Average impact energy
(Celsius) (J) (J)
Standard -20 greater than or equal to 27
greater than or equal to 400 greater than or equal to 480 greater than or equal to 20
Bend test
Test Fil Side Turn Root Weld Gas protection Amperage Arc Voltage Position
Polarity
Qualified Qualified Qualified Qualified DC CO2 230A-260A 27V-30 VFH Vu Vd OH
Color: silver black
Material: Solder wire
Size: 0.8MM
Package Contents: 1 * 0.8mm flux-cored solder wire
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
