Voltage: 36V


Rated power: 1000W


Applicable: 700-1000W motor


Color: Silver


Material: Metal


Controller wiring instructions


1. For the motor to work, the first four connectors must be connected first. First, connect the two thicker blue and white wires from the controller to the motor, the blue wire to the motor's red wire and the white wire to the motor's black wire.


2. Then connect the two red and black wires from the controller to the battery, the red wire to the battery's positive terminal and the black wire to the battery's negative terminal. Then connect the third wire to the speed controller (the speed controller
has three wires, the red wire connects to the red wire and the black wire connects to the black wire). Connect the electric lock, open the door lock, start the motor and it will run.


Note: Do not connect the power cable incorrectly, otherwise it may burn.


Different batches may cause the product's appearance, text and color to differ, which does not affect use


Package contents:


1 x brushed controller


Only the above package content, excluding other products


Note: Light reflection and different monitors may cause the product's color to look slightly different in the picture than in reality. The allowed measurement error is +/- 1-3 cm.
