Code cloner for an extra remote control in reserve: RF code cloner in remote control design to clone over your old remote controls' codes. Perfect for transferring/copying the code for garage doors, automatic gates, security systems, and household equipment.

\r

Always a backup close at hand: Copy the functions from your original remote control with this 4-channel RF duplicator with learning functions, so you always have a backup or extra garage door opener at hand.

\r

Perfect for the garage door: Compatible with fixed frequency of 433 MHz, which is the frequency that most garage door openers use.

Compatible with the following chipsets: 2260 (all manufacturers) 2262 (all manufacturers) PT2264, 5326 (all manufacturers) SC5262, HT600, HT680, HT6207, HT6010, HT6012, HT6014, SMC918 series, 527 (all manufacturers) 1527 (all manufacturers) 2240 (all manufacturers) HCS101, HCS200 HCS201 (parts of the code) HCS300 HCS301 (parts of the code) Parts of singlechip.

\r

NOTE: This model is not suitable for rolling code. In that case, you need a different model. Cannot copy the car alarm remote (for security reasons).

\r

\r

Specification:

\r

Signal transmission speed: 50-60 KHz
Voltage: 12 V
Current: 10 mA
Frequency: 433 MHz
Signal transmission power: 10-12 mW
Signal transmission distance: Up to 50 m in open area
Color: Black/silver
Battery: 2V27A battery (included)
Size: 6x4x1.2 cm
Weight: 28 g

\r

Package includes:

\r

1 x Universal code cloner - remote control

\r

\r

How to copy:

\r

Step 1: Remove the old code from the duplicator

\r

1. Continuously press buttons A and B until the LED light flashes

\r

2. Release button B (continue pressing button A) and slowly press button B 3 times, LED flashes

\r

3. Release button A, code removal is complete

\r

Step 2: Copy code from the original transmitter

\r

1. Place the duplicator as close to the original transmitter as possible.

\r

2. Press and hold button A on the original transmitter, press and hold button A on the duplicator, until you see the duplicator's LED flash.

\r

3. Release both buttons, code copying complete. Copy the next button in the same way.

\r

Reset function:

\r

Press and hold buttons C and D for 3 seconds, LED flashes, all buttons return to the last copied codes.
