1. Professional Distribution Amplifier: The 12-channel distribution amplifier is a professional distribution amplifier with IRS Loop through. 2. Signal Amplifier: 12-way distribution amplifier SAT and TERR radio signals are sent through a distribution amplifier. 3. High Performance: The 12-port distribution amplifier provides a professional solution with low noise and high gain. 4. F-type Female Connector: The 12-way distribution splitter is designed with an F-type female connector. 5. With LED Indicator: This distribution splitter can be displayed with an LED indicator for convenient use.
Item Type: 12-channel Distribution Amplifier
Material: Plastic
Product Size: Approx. 24x12x5cm / 9.4x4.7x2.0in
Ter Frequency Range: 87MHz-782MHz
Ter/IRS Input (F-type female): 1
Ter Tap Output (F-type female): 12
Sat loop through (F-type female): 87-2350MHz
Red Compliance: Class 3
Ter Gain: 10dB
Maximum Output Terr (iMA3 -60dB): 90dbuv
Maximum Noise Figure: ≤4db
SAT by loss: 4db
Resistance: 75Ω
Loop through passing: 13 18v 22kHz DiseQC
Connector Specification: EU Plug
Remote DC (output via Ter): 12V DC
Remote DC Consumption: 100mA (max)
Power Indicator: LED
1 x 12-channel Distribution Amplifier
