Description:\r
These wire inserts can effectively improve screw connection and significantly improve reliability. Used in all kinds of low-strength materials, wire inserts can greatly improve the wear resistance of the screw connection and avoid thread damage.\r
\r
Features:\r
These self-tapping wire inserts can be installed directly and you don't need to tap first.\r
\r
They are used in low-strength materials such as aluminum, magnesium, can avoid thread damage and get good connection performance, to increase connection strength and improve connection condition.\r
\r
Used for parts that require frequent removal, it can significantly improve the service life and wear resistance of the screw thread.\r
It can prevent the screw from loosening, especially used for products that require a high insurance coefficient.\r
Easy to maintain, install a wire insert in a damaged screw hole, then the screw hole can be used as normal, to avoid loss of the workpiece.\r
\r
Specifications:\r
Material: Stainless steel SUS303\r
Inner Thread Size: M3 (diameter) x 0.5 (pitch)\r
Length: 6mm\r
Outer Thread Size: M5 (diameter) x 0.5 (pitch)\r
Drill Diameter: 4.5~4.6mm (plastic); 4.6~4.7mm (aluminum alloy); 4.7~4.8mm (cast iron)\r
Min. Drill Depth: 8mm\r
\r
Quantity: 20pcs\r
Weight: 9g (approx)\r
\r
Package includes:\r
20 x Threaded inserts
