600P/R Magnetoelectric Incremental Rotary Encoder 5V-24V AB 2-Phase Shaft 6mm

600P/R Magnetoelectric Incremental Rotary Encoder 5V-24V AB 2-Phase Shaft 6mm

Name: 600P/R Magnetoelectric Incremental Rotary Encoder 5V-24V AB 2-Phase Shaft 6mm
SKU: ZS-EU-0708003946
Price: 345 SEK
Availability: InStock

345 kr

I lager

Mån, 20 jul - fre, 24 jul

Säker betalning

Nöjd kund-löfte

30 dagars öppet köp

Produktbeskrivning

Welcome to our store!

1. This product has 600 p/r (single-phase configuration 600 pulses /R, two-phase 4 frequency doubling to 2400 pulses).
2. The power supply is DC5-24V. Stable working performance and good working conditions.
3. AB 2-phase output rectangular orthogonal pulse circuit, the output for NPN open collector output type.
4. It can be used to measure the rotational speed, angle and acceleration of the object and length measurement.
5. Suitable for intelligent control of various displacement measurements, automatic fixed-length leather guillotines, steel cut-to-length control, height and weight scales, student racing robots.

Features:1. This product has 600 p/r (single-phase configuration 600 pulses /R, two-phase 4 frequency doubling to 2400 pulses).2. The power supply is DC5-24V. Stable working performance and good working conditions.3. AB 2-phase output rectangular orthogonal pulse circuit, the output for NPN open collector output type.4. It can be used to measure the rotational speed, angle and acceleration of the object and length measurement.5. Suitable for intelligent control of various displacement measurements, automatic fixed-length leather guillotines, steel cut-to-length control, height and weight scales, student racing robots.

Item

1pc Incremental Rotary Encoder 600 p/r 6mm Shaft 5-24v
Specifications:

Pulses: 600 p/r (single-phase configuration 600 pulses /R, two-phase 4 frequency doubling to 2400 pulses)
Power supply: DC5-24V
Shaft: 6*13mm/0.23*0.51 \"
Size: 38*35.5mm/1.49*1.39 \"
Output: AB 2-phase output rectangular orthogonal pulse circuit, the output for NPN open collector output type
Maximum mechanical speed: 5000 R / min
Response frequency: 0-20KHz
Cable length: 1.5 meters
Applications:

1. It can be used to measure the rotational speed, angle and acceleration of the object and length measurement
2.
Suitable for intelligent control of various displacement measurements,
automatic fixed-length leather guillotines, steel cut-to-length control,
civilian measured height human scale, Student racing
robots
Notice:

AB 2-phase output must not be directly connected to VCC, otherwise

it will burn the output transistor, as different batches, and it may happen that

the terminal is missing. (Green = A-phase, white = B-phase, red = Vcc power +, black = V0)
Package content:

1 x Encoder 600P/R Incremental Rotary Encoder
