1. Multifunctional digital display meter can measure AC voltage and current, active power, apparent power, and power factor simultaneously.
2. Uses high-strength flame retardant material, safe and reliable.
3. High measurement accuracy, stable performance.
4. Compact size and robust structure, easy installation.
5. No external AC transformer is required to measure current within 99.9A.
Features:
Multifunctional digital display meter can measure AC voltage and current, active power, apparent power, and power factor simultaneously.
Uses high-strength flame retardant material, safe and reliable.
High measurement accuracy, stable performance.
Compact size and robust structure, easy installation.
No external AC transformer is required to measure current within 99.9A.
Simply pass the wire in the measuring loop through the small round hole on the right side of the meter to complete the measurement.

Specification:
Measuring voltage: AC80-300V, AC200-450V (Optional)
Measuring current: AC100A (additional transformer required if greater than 100A)
Power supply: no power supply required
Measurement accuracy: 0.5%
Overall dimensions: 54 * 80 * 64mm / 2.1 * 3.1 * 2.5in Installation: 35mm DIN rail installation
Package list:
1* Multifunctional meter
Note: New and old styles are shipped randomly
