General

The black heat shrink tubing is an assortment of 625 pieces, consisting of 8 different sizes from 1 to 10 mm. Made of high-quality thermoplastic polyolefin, it is ideal for protecting welded joints, bundling wires, and providing electrical resistance. This flame-retardant and flexible tubing is lightweight, and offers excellent electrical insulation and corrosion protection.

Technical specifications

• Material: Polyolefin

• Available diameters: 1 mm, 2 mm, 3 mm, 4 mm, 5 mm, 6 mm, 8 mm, 10 mm

• Flammability: Flame retardant

• Operating temperature: -55°C to +125°C

• Minimum shrink temperature: +70°C

• Full shrink temperature: +110°C

• Shrink ratio: 2:1

• Tensile strength: 10.4 MPa

• Dielectric strength: 15 kV/mm

• Quantity per size: 150 pcs x 1.0 x 40 mm, 120 pcs x 2.0 x 40 mm, 100 pcs x 3.0 x 40 mm, 90 pcs x 4.0 x 40 mm, 60 pcs x 5.0 x 40 mm, 45 pcs x 6.0 x 40 mm, 30 pcs x 8.0 x 40 mm, 30 pcs x 10.0 x 40 mm

Usage

Heat shrink tubing is primarily used for:

• Connecting wires

• Corrosion protection of solder joints

• Insulation of wire ends and cable bundles

• Bundling electrical wires

Other information

• Package includes: 625 heat shrink tubes and 1 storage box
