1. Industrial master chip, 16 AD sampling accuracy, temperature, charging current, discharge current accurate real-time display. 2. Automatic focusing MPPT tracking charging, high charging efficiency, uninterrupted detection during charging, bidirectional focus tracking. 3. Large LCD display, all adjustable parameters. 4. Three-stage charge management, effectively protects the battery. 5. Built-in short-circuit protection, open-circuit protection, reverse protection, overload protection.

Features:

• Industrial master chip, 16 AD sampling accuracy, temperature, charging current, discharge current accurate real-time display.
• Automatic focusing MPPT tracking charging, high charging efficiency, uninterrupted detection during charging, bidirectional focusing.
• Large LCD display, all adjustable parameters.
• Three-stage charge management, effectively protects the battery.
• Built-in short-circuit protection, open-circuit protection, reverse protection, overload protection.
• Two-way anti-backflow circuit for mos tube, high-power charging mode, ultra-low heating.
Specification:
Condition: 100% Brand New
Material: ABS
Color: As the picture shown
Options: 40A, 50A, 60A, 100A
Battery Voltage: 12V 24V Auto
Solar Panel Voltage: 12V, 18V solar panel, 24V, 36V solar panel
Float Charge: 13.7V (default, adjustable)
Discharge Stop: 10.7V (default, adjustable)
Discharge Reconnect: 12.6V (default, adjustable)
Self-consumption: <10mA
USB Output: 5V / 2A Max
Package List:
1 x Controller
1 x User Manual

Note:

The product is a simplified version for MPPT.
