Description

General Description

The belt tension gauge is a universal tool designed to accurately measure the tension of secondary drive belts on various vehicles, including motorcycles and ATVs. With a 10 lb capacity, this tool makes belt tension adjustment easy, ensuring optimal performance and extended belt life.

Technical Specifications

Item Type: Belt Tension Gauge

Material: Metal Alloy

Capacity: 10 lb

Markings: Clear and easy to read for accurate measurements

Compatibility and Accessories

Fits most motorcycles with secondary drive belts

Includes: 1 x Belt Tension Gauge

Installation

Position the small O-ring at the 10 lb mark.

Place the U-shaped belt bracket against the bottom of the belt at a 90-degree angle.

Using the large O-ring as a reference point, note the reading.

Push up against the bumper rubber until the small O-ring touches the bottom of the tool body.

Adjust the large O-ring to the reference point to measure belt deflection.

Usage

This gauge is ideal for the following situations:

Use after belt replacement

Adjusting belt tension

Motorcycle wheel repair
