Operating voltage: 10V-55V
Output voltage: linear under load
Input current: requires current greater than the motor's operating current
Output current: depends on load size
/>Output current: 0-100A
Continuous current: 60A
Quiescent current: 0.01A (standby)
Maximum power: 3000 W (power = voltage * current)
Motor control: 0.01-3000W,
12V: 720 W (max), 24 V: 1440 W (max),
36 V: 2160 W (max.), 48 V: 2880 W (max),
50 V: 3000 W (max).
Button hole: 7mm
Speed type: adjustable current
Speed mode: linear potentiometer ON / OFF 270 degrees
Speed range: 0% -100%
Frequency control: 15 KHZ
Speed control: potentiometer (with switch)
Button specifications: 100K (with switch)
Speed type: flow control
Expected rotation: support
Digital positioning screen: 0-100 (maximum speed percentage)
Board size: 120 * 96mm / 4.72 * 3.78 inches
Color green
Material: plastic
Package contents:
1 * Motor Speed Controller
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
