Item Type: OBD2 Scanner
Material: ABS

SSID: WiFi OBDII
IP: 192.168.0.10
Port: 35000
Communication: WIFI
Main Chip: ST
Support System: For IOS, for Android, for Symbian, for Windows
Working Voltage: 9v-16v
Working Current: 65mA
Standby Current: 45mA
Operating Temperature: -40 ℃-85 ℃
Working Humidity: Less than 60%
Compatible Systems:
Software Support Platform: For Windows XP, for Windows 7/8, for IOS, for Android, for Symbian.
Compatible Software:
For Windows: For ScanMaster ELM, for ScanTool.net, for PCMSCAN ELM, etc.
For IOS: For Auto Doctor, for Mini OBDII
For Android: For Torque, for DashCommand, for OBD Car Doctor, for Auto Doctor, for Mini OBD, for EOBD, etc.
For Symbian: For OBDScope
Features:
1: Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
2: Clear trouble codes and turn off the Malfunction Indicator Light (Check Engine Light)
3: Display current sensor data, including:
4: Engine RPM
5: Calculated Load Value
6: Coolant Temperature
7: Fuel System Status
8: Vehicle Speed
9: Short Term Fuel Trim
10: Long Term Fuel Trim
11: Intake Manifold Pressure
12: Timing Advance
13: Intake Air Temperature
14: Air Flow Rate
15: Absolute Throttle Position
16: Oxygen sensor voltages / associated short term fuel trims
17: Fuel System Status
18: Fuel Pressure
19: Many others
Supported Protocols:
1.SAE J1850 PWM (41.6Kbaud)
2.SAE J1850 VPW (10.4Kbaud)
3.ISO9141 2 (5 baud init, 10.4 Kbaud)
4.ISO14230 4 KWP (5 baud init, 10.4 Kbaud)
5.ISO14230 4 KWP (fast init, 10.4 Kbaud)
6.ISO15765 4 CAN (11bit ID, 500 Kbaud)
7.ISO15765 4 CAN (29bit ID, 500 Kbaud)
8.ISO15765 4 CAN (11bit ID, 250 Kbaud)
9.ISO15765 4 CAN (29bit ID, 250 Kbaud)

1 x
OBD2 Scanner
