Mating type: male plug + female socket; Connection mode: One-click button plug in/unplug; Locking: automatic insertion, self-locking device; Protection level: IP68 (2M/2H) (mated); Assembly: soldering.

Cable standard: Cable specification: 2.5-4.0mm / 14-12AWG; Cable diameter range: 8.0-12.0mm; Contact diameter x quantity: 2.7x2; Durability: equal to 1900 matings/unmatings cycles.

Electrical characteristics: Rated current: 20a; Operating voltage (AC. V. RMS): 500V; Withstand voltage: 2500V; Contact resistance: Less than 1M ohm; Insulation resistance: 1000M ohm; Do not plug in when power is on.

Material properties: Shell material: High-performance PBT plastic material; Temperature range: -40 to 80 ; High temperature aging: 85 /168 h; Temperature rise: 20A 30K ; 25a 40k ; 30a 50k ; Flame retardant: UL94 V-0; Sealing: High-quality silicone ring; Contact core: copper alloy (gold-plated)

Widely used: in various challenging environments. Suitable for mechanical, server, photovoltaic, energy storage, power grid, automotive, marine, communication, detection, measurement, industrial control, audio-visual equipment, stage equipment, etc.



Type: 4 Pin

Colour: Black

Material: Plastic



Package Contents:

1 * connectors



Only the above package content, other products are not included.

Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3 cm.
