Features: Brand new and high quality

The spot welding control module is developed for DIY or simple battery welding. It is mainly used for welding single batteries or battery packs with nickel-plated sheets, such as 18650 lithium battery nickel plating 0.15 and 0.2mm steel sheet, 500W transformer can be welded directly.

It is intended for welding other battery materials and different thicknesses, such as polymer battery electrodes without nickel plating, must be combined with sufficient power transformer to weld.

Can be set to save the last operation, the module dual pulse trigger, turn off optional trigger for time, you can change dual pulse to single pulse trigger.

Multi-group data 12864 visual display, intuitive operation, convenient, simple encoder parameter adjustment can make the operation simple and fast.

With 0-9999 welding counting function, with 5 groups of sample storage parameters, can be stored even when power is off, the number of welds can be seen at a glance.



Specifications: Current: 40A / 100A (Optional)

Display: 12864 LCD display

Display Board Size: 85 x 45mm/3.39x1.77in

Main Board Size: 85 x 45mm3.39x1.77in

Package Size: 10 x 9x 2cm/3.93x3.56x0.79in

Package Weight: 74-86g



Package includes: 1 x Main Board

1 x Display Board

1 x Cable



Note: Due to problems with lighting effects and shooting angles, there will be certain tolerances in the product, please understand.

Please allow 0-1cm error due to manual measurement.

The module has mains voltage compensation function, so voltage calibration must be performed when the first machine is installed, and in the future, as long as the module's power transformer is not replaced, it does not need to be recalibrated. Of course, when you feel that the display's voltage is inaccurate, it can be calibrated.
