Smaller connectors and cables save space in the equipment.

Provides four-way signal transmission according to industry standards.

Data rate: SAS 32GbPs per channel.

Meets SAS5.0, Slim SAS SFF-8654 PCIE MCIO specifications Mechanical properties.

Applications Servers, Data Storage, Workstations.



Mechanical properties:

Insertion force: 55.5N maximum

Extraction force: 49N maximum

Rated durability cycle: 250 cycles minimum

Electrical performance:

Voltage: 30VDC per contact

Simulas4i connector: 80MOHM maximum, initial, 20MOHM maximum stress test.

Dielectric withstand voltage: 300 volts minimum for 100 milliseconds

Insulation resistance: 10MOHM minimum between adjacent pins

Characteristic impedance: 100OHM

Signal integrity:

Mating connector impedance: 10010% ohm

Common mode impedance: Meets SAS5.0 specification

Insertion loss: Meets SAS5.0 specification,

Maximum crosstalk: Meets SAS5.0 specification

Product environmental compliance:

ROHS2.0: Compliant

RoHS: Compliant

Color: Black

Material: Oxygen-free copper

Size: 0.5M



Package contents:

1 * Cable



Only the above package content, other products are not included.

Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The allowed measurement error is +/- 1-3cm.
