Brand new and high quality

Instructions:

How to program:

1. Erase existing data: Press the learning button 8 times. Response: LED flashes 7 times.

2. Learn remote control code: press learning for key one, two or three times (see below).

LED lights up: learning mode is active. Press any button on the remote control.

The LED indicator flashes three times: learning is complete.

3. Test: after the above operation, the receiver board can be controlled by the remote control.

More transmitters with different IDs can be learned and stored additionally, starting from step 2.

A mix of different modes is possible.

Button operation (sets mode and starts pairing process):

Press once: Momentary Mode

Press twice: Self-locking Mode (Toggle Mode for the 4 channels)

Press three times: Interlocked mode (selected channel active and cleared, if another channel becomes active)

Features:

Fine craftsmanship, stable and reliable security, high confidentiality.

RF signal can pass through walls, floors and doors, control the switch receiver from any place within a reliable distance. Max range is up to 15 m without obstacles.

Widely used for remote control switches, receiver modules, motorcycles, car anti-theft products, home security products, electric doors, roller shutter doors, for windows, remote control sockets, remote control LED, remote audio remote control electric doors, garage door remote control, remote control retractable doors, remote volume gate, panel doors, remote control door openers, door closing device control systems, remote control curtains, alarm systems, alarms, remote control motorcycle remote control electricity for cars, remote control MP3.

Remote control only, other accessories demo in the picture is not included!

Tips:

If your transmitters do not use EV1527 encoding, they will not connect to the receiver.

Specification:

Module material: Plastic+Metal

Working voltage: DC3.3-5V

Quiescent current: Less than 5mA

Working frequency: 433MHz

Receiving sensitivity: -108dB

Receiving distance: 15 meters above

Frequency band: 0.2MHz

Working temperature: -25 to 75

Working mode: Momentary, Self-locking, Interlocking

Output: 4-channel CMOS level signal Corresponding remote control ABCD 4-buttons

Compatible transmitter encoding type: EV1527

Color: As pictures shown

Controller dimension: 6.5x4.0x1.5cm/ 2.56x1.57x0.59in

Quantity: 1 set

Note:

1.No retail package.

2.Please allow 0-1cm error due to manual measurement. please make sure you do not mind before you bid.

3.Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!

Package includes:

1 pc x Receiver module

1 pc x Remote control
