The CAT 8.1 system supports high data rates of up to 40 GBit/s even without switching to fiber optics. In combination with installation cables and RJ45 connectors according to the CAT 8.1 standard, the patch cable can be integrated into a high-quality high-speed data link.

The 20-meter network cable supports 25GBase-T and 40GBase-T Ethernet networks (40 gigabit compatible) and is backward compatible with 10BASE-T, 100BASE-TX, and 1000BASE-T.

With a transmission bandwidth of up to 2,000 MHz, the Ethernet cable has 4 times greater bandwidth than CAT 6A cables.

S/FTP overall shielding: aluminum foil for individual wire pairs (PiMF) and aluminum braided shielding for the cable jacket

Equipped at both ends with RJ45 connectors (8P8C) with 50 μm gold-plated contact surfaces and snap-lock protection.

The CAT-8 network cable is suitable for Power over Ethernet (PoE, PoE+, UPoE, 4PPoE) and HDBaseT.

Low-smoke and halogen-free LSZH cable jacket for increased data cable safety

AWG : 26/7 (stranded)
Specification : CAT 8.1
Cable jacket diameter : 6.2 mm
Shielding class : S/FTP (PiMF)
Number of shields : 2 x
Connector : EIA/TIA-568 B
Markings : WEEE, CE
Bend protection : two-sided
Cable type : cat. 8.1 raw cable
Material cable jacket : LSZH
Inner conductor material : CU (copper)
LSZH compliant : yes
Type 1, shielding : Foil (alu) PiMF
Type 2, shielding : Braided shield (alu) overall shielding
Connection, housing material : PVC
Connection, contact material : Gold-plated 50µm
Connection, shielding : yes
Connection, type : RJ45 connector (8P8C)
Connection 2, type : RJ45 connector (8P8C)
Latch protection : two-sided
Color : black
Consumption unit : 1 pc. unpackaged
Special feature : Length indication on the connector
Cable length : 20 m
Color version : black
Jacket material : LSZH
