Feature:
1. Made of high-quality materials, lightweight, rainproof and durable.
2. The LCD screen can clearly display the status and data, and the button operation is quick and convenient.
3. The controller works silently and is sensitive to the status of the electric bicycle. It is suitable for electric bicycles, cars and motorcycles.
4. Each cable has a different color for easy installation of the display panel on an electric bicycle.
5. With LCD screen holder, it is very easy to install and use.
Specification:
Item Type: Electric Bicycle Accessories
Material: Aluminum Alloy
Product Name: Instrument Brake Controller
Rated Voltage: 24V
Rated Power: 250W
Undervoltage: 21V
Over Current: 16A
Controller Diameter: Approx. 46.6mm/1.83in
Controller Length: Approx. 88mm/3.46in
Description:
P00: Brightness, level 1 is the darkest, level 3 is the brightest;
P01: Mileage unit, 0: Km; 1: Mile;
P02: Voltage level: 24V, 36V, 24V Standard;
P03: Sleep time: 0 - No sleep; Other numbers are sleep time, range: 1-60; Unit: Minute;
P04: Wheel diameter: The unit is inches, accuracy: 0.1;
P05: Speed magnet number: Range: 1-100;
P06: Speed limit: Range 0-100%, 100 means unlimited speed;
P07: From zero, non-zero start setting, 0: Zero start; 1: Non-zero start;
P08: Soft start, hard start setting, 0: Hard start, 1: Soft start;
P09: Automatic cruise control, 0: Cancel cruise control function, 1: Automatic cruise control starts after 7 seconds of acceleration;
P10: Use password, 0: No password, 1: Password required;
P11: Password: 00-99;
P12: Odo Press the Clear setting button for 5 seconds to clear Odo.
Packing List: 1 X 24V 250W LCD Display 1 X Controller 1 X 24V LCD Display
