[RM]High Power Motor Drive Module BTS7960 43A for Smart Car Electrical Components

[RM]High Power Motor Drive Module BTS7960 43A for Smart Car Electrical Components

Name: [RM]High Power Motor Drive Module BTS7960 43A for Smart Car Electrical Components
SKU: 11FD-5.7-5601
Price: 287 SEK
Availability: InStock

287 kr

I lager

Fre, 31 jul - tor, 6 aug

Säker betalning

Nöjd kund-löfte

30 dagars öppet köp

Produktbeskrivning

Item Type: Motor Drive Module_x005fFunction:_x005fDual BTS7960 high current (43 A) H-bridge driver;_x005f5V is isolated from MCU to effectively protect MCU;_x005fOn-board 5V power indicator;_x005fVoltage indication at the output of the motor driver;_x005fHeat sink can be welded;_x005fPIN Definition:_x005f1. RPWM: Turn right to PWM_x005f2. LPWM: Turn left PWM_x005f3. R_EN: Turn right to enable (active high)_x005f4. L_EN: Enable left turn (active high)_x005f5. R_IS: Right turn current warning (can float)_x005f6. L_IS: Left turn current warning (can float)_x005f7. VCC: (5V)_x005f8. GND_x005fConnection method:_x005fMethod 1:_x005fVCC: 5V from single-chip microcomputer (MCU)_x005fGND: GND of microcontroller (MCU)_x005fL_PWM: PWM or 5V from microcontroller (MCU) for CCW (CW) turns_x005fR_PWM: PWM or 5V from microcontroller (MCU) for CW (CCW) turns_x005fR_EN and L_EN: 5V from microcontroller (MCU)_x005fMethod 2:_x005fVCC: 5V from single-chip microcomputer (MCU)_x005fGND: GND of microcontroller (MCU)_x005fL_PWM: 5V from microcontroller (MCU) for CCW (CW) turns_x005fR_PWM: 5V from microcontroller (MCU) for CW (CCW) turns_x005fR_EN and L_EN: PWM from microcontroller (MCU)_x005fOnly four wires (GND. 5V. PWM1. PWM2) are needed from MCU to the drive module;_x005fIsolation chip 5 V power supply (can be shared with MCU 5 V);_x005fCan make the motor rotate forward, two PWM input frequencies up to 25kHZ;_x005fTwo heat flows through a fault signal output;_x005fIsolation chip 5V power supply (can be shared with MCU 5V), you can also use the on-board 5V power supply;_x005fPower supply voltage 5.5V to 27V; 1. The driver uses the BTS7960 chip, which consists of a high-power driven full H-bridge drive module with thermal overcurrent protection. 2. The dual BTS7960 H-bridge drive circuit has powerful drive and braking functions, effectively isolating the microcontroller and the motor driver and high current 43A. 3. This product can realize the forward and reverse rotation of the motor, and the two PWM inputs have a maximum frequency of 25kHZ. 4. 5V isolation from single-chip can effectively protect single-chip. 5. The product is characterized by stable performance and long service life.1 x_x005fMotor Drive ModulePlease note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.
