1. 5V 2-channel self-locking relay module with high reliability. 2. Made of high-quality material with stable performance, durable. 3. Practical relay module, easy to install and convenient to use. 4. High accuracy and strong stability, practical and safe to use. 5. Trigger mode is low pulse trigger, more reliable and convenient.
Item Type: Relay Module
Material: Metal
Working Voltage: DC 5V
Working Current: 1 relay pulls in 70MA, 2 relays pull in 140MA
Static Working Current: 0.2mA
Relay Load Current: AC 250V/10A, DC 30V/10A
Trigger Mode: Low Level Trigger
Pin
V: Power positive
G: Power negative and trigger signal ground terminal;
T (T1/T2/T3/T4): Trigger signal input (0.2-2s low pulse)
NO: Relay normally open port
COM: Relay common port
NC: Relay normally closed port
Instructions: When power is on, the relay is off. Click the trigger port (T1/T2/T3/T4 port) to pull in the relay (and hold), click the relay again to disconnect, and so on.
1 x Relay Module
