Self-test: press the nail three times to test, the power is on. Alarm: The LED light flashes if a problem is detected during self-test or operation. The standard deviation for 3D repeatable pressing is approximately 0.005 mm, which is accurate. If you choose 3D-touch, 3D printers will give you a pleasant experience with first-class masterpieces. Innovative electromagnetic: super energy-saving energy: in sleep mode, while the pressure is pulled out or retracted, no current flows through the solenoid valve and the standby current of the entire unit is less than an average of 15 mA, while 'It is in working condition, while the foot is walking, suddenly at about 100 ms, the unit has a flow of less than 300 mA.
Low power consumption further reduces Joule heating to avoid thermal problems. Bed width selection: 3D-Press does not use any light and is not close to the sensors (inductance/capacitance).
The 3D press provides high precision thanks to Hall effect control. Therefore, the bed material can be freely selected. Optimized structure: larger volume: 3DPress is a technology-intensive person. The build size can be larger than other existing automatic bed leveling sensors.
3D-Press is a fully automatic universal 3D printer hot bed leveling probe (automatic leveling probe). Its advantages are simplicity, compactness, high precision, good compatibility and compatibility with all bed materials, such as glass, metal, wood, plastic, acrylic, etc.
Wiring:
3D-press wiring:
3PIN wiring: Black (-, GND)
Red (+5V)
Blue (control signal)
2PIN: Black (-, GND) Yellow (Zmin)
Precautions:
Some 3D printer motherboards may have an external 5V power supply if the 5V power supply is insufficient. It is difficult to press the probe or the logic circuit protects the main restart during operation. If it is generally recommended to use the DC-DC step-down module to supply the main power supply.
1. +5V and GND should not be connected for a long time.
2. Try to stay away from strong magnets, motors and fans etc. with magnetic components
3. Accidental impact on the probe's aluminum rod can damage or affect detection accuracy
4. Adjustment or reassembly of the probe's adjustment screw requires thread glue
5. Install the probe to prevent deformation of the housing
6. Pull the aluminum rod hard Will damage or affect detection accuracy
color: photo color
Material: plastic + metal
Package contents:
1 * pressure probe 3D white
2 * M2.5 screw
2 * M2.5 nut
1 * DuPont line 2pin female to female 1m
1 * DuPont line 3pin female to female 1m
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The allowed measurement error is +/- 1-3 cm.
