Multifunctional parameters allow you to safely measure AC/DC voltage, AC/DC current, resistance, diode, capacitance, frequency, etc. Type K thermocouples can be used to measure temperatures up to 250 degrees Celsius, allowing ambient temperature measurement without connecting the probe. When measuring current and/or voltage, press the SEL button to display the frequency value.

Intelligent design - High-quality PM18C and innovative packaging design to make it look like a gift. Made of high-quality materials and the entire structure is solid and durable. The multimeter is ergonomic, comfortable and relaxed to use.

Multifunction - Transistor test, automatic shutdown, low battery warnings and 2.75 inch white LCD display and allows you to easily measure the backlight under difficult conditions. low light. The back of the console allows you to put your hand on the release work. And a flashlight on the back in the dark depths would be invaluable.

Wide application - Data storage mode saves the screen reading in memory. As a universal measuring tool, widely used in schools, laboratories, factories and other social occasions. It will become one of your reliable friends. It helps you solve the problem of household appliances or cars.

Product description:

DMM is a very useful tool for electricians, hobbyists and professionals.

It can be used for diagnosis, repair, assembly and wiring.

Also includes short circuit protection and automatic shutdown function.

Function:

1. This innovative product has a rich and modern design

2. A large digital backlit LCD screen and rear flashlight

can be used in low light.

3. Non-contact voltage test to make testing more convenient and safer

4. Quick display of results to update the speed 2-3 times/sec

5.18C: l uses a type K thermocouple at the test temperature (included).

Specification:

DC voltage range and accuracy: 600mV/6V/60V/600V ±(0.5%+3), 1000V ±(0.5%+3)

AC voltage range and accuracy: 6V/60V ±(0.8%+3), 600V/750V ±(1%+10)

DC current range and accuracy: 60 μA/60 mA /600 mA ±(0.8%+3), 20.00 A ±(1.2%+3)

AC current range and accuracy: 60mA/600mA ±(1%+3), 20A ± (1.5% + 3) )

Resistance range and accuracy: 600Ω/6KΩ/ 60KΩ/600KΩ/6MΩ ±(0.8%+3), 60MΩ ±(1.2%+3)

Frequency range and accuracy: 0/600/6k/60k600k/6m/10Mhz ±1.0%+3

Temperature range and accuracy: -20℃-1000℃/ -4℉-1832℉±1.0％+3< /p>

Maximum value：Value 6000

General parameters

Battery: 4 x 1.5V AA (not included)

Safety level: CE, EN6 1010-1-2-030 CAT III 1000V CAT IV 600V EN61010-2-033, ROHS

Package includes:

A digital multimeter

A test cable (two pairs)
