Feature: 1. Dual Hall Sensors: The electric bicycle assist sensor housing has dual Hall sensors to detect cycling. 2. 12 Magnets: With 12 magnets, the accuracy is higher than with 5 magnets, and the distance from the sensor is longer. In terms of sensitivity, it is 2-3 times higher than that of ordinary 5 magnets, and there is no false activation. 3. Pulse Signal: Installed on the right side of the pedal by default, with 12 pulses in a circle. The chip filters and identifies the pulse signal to determine the direction of rotation. The forward direction is valid and the reverse direction is invalid. 4. LED: When the pedal moves forward, the sensor will output a pulse signal, and the LED is at a low level (with or without a pulse signal), so the LED does not flash. 5. Features: Made of high-quality material, strong and durable. Professional manufacturing, stable performance and high reliability. Easy installation and disassembly, waterproof interface. Specification: Item Type: Electric Bicycle Assist Sensor Material: PC plastic Hall Electrical Life: >20M times Rated Voltage: 4.5-6V (DC) No Brake Current: < 5mA With Brake Current: < 6mA Insulation Dry State: > 20M ohm Insulation Wet Conditions: > 2M ohm Brake Equivalent Time: <0.001S Equivalent Distance: 2-3mm. Package List: 1 x Sensor Cable 1 x Sensor Sheet
