Features:

1. Each product has a unique Manufacturing Part Number label on the inner package that proves it has been qualified, which include Part Number, Model Number and inspection date information;

2. If you have any questions about the item, please provide us the Manufacturing Part Number for checking, your profits will be guaranteed.

3. Made of high-quality PA66 materials, sturdy structure, beautiful appearance and long service life.

4. The switch is easy to install, the switch status can be highlighted by the LED indicator.

5. With yellow light indicator and on/off switch, suitable for high-power electrical appliances and equipment.

6. The product structure is simple, suitable for families and large companies, such as all kinds of lamps and electrical appliances controlled by power cords.

7. This double pole on/off switch is designed to replace the old broken switch or add a new switch that was not there before.

Specifications:

Material: PA66

Color: Black+Red

Mounting method: Screw connection type

Ambient temperature: -40C+85C

Withstand voltage: 2500V/5S/0.025mA

Rated current and voltage: 30A 220V

Impulse voltage: 0.5NM0.04NM

Contact resistance: 0.02

Pull test: 30N/min

Insulation resistance: 100M

Operating life: 10,000 times

Dielectric strength: 1500VAC/min

JK-Flammability: UL94V2 Level

Product safety: IP65 Waterproof

Applicable power cord: H03VVH2-F:2x0.5mm / H03VVH2-F:2x0.75mm / 2.2x4mm / 3x2.5mm

Product materials: in line with the latest

EU ROHS environmental protection standards.

Size: 11.4x3.5cm/4.48x1.37inch(LxW)

Weight: 88g

Note: Connection method: loosen the screw, insert the wire between the two splints, and then tighten the screw. (The wire is not wrapped around the screw)

Warm reminder: Push the electrical appliance to the Inch-Inch button and connect the power source to the Inch0Inch button.

Package includes: 1 x Inline Cord Switch
